Suspension assembly.
Electrode: 1x, 120mm, PG 13,5
Application: flow channel, tanks,
bassin.
Electrode fitting: Bajonet, PPS.
-
Successor
-
Standard products
- Reliable, robust and low-maintenance
Technical excellence
Simplicity
-
Specialized products
- Designed for demanding applications
Technical excellence
Simplicity
Variable
FLEX selections Technical excellence Simplicity - F
- L
- E
- X
Fundamental selection
Meet your basic measurement needs
Technical excellence Simplicity - F
- L
- E
- X
Lean selection
Handle your core processes easily
Technical excellence Simplicity - F
- L
- E
- X
Extended selection
Optimize your processes with innovative technologies
Technical excellence Simplicity - F
- L
- E
- X
Xpert selection
Master your most challenging applications
Technical excellence Simplicity Variable
-
3 documents
-
-
Technical Information (TI)
Technical Information CPA 530
Assembly
EN 01/02/1999Language:
English
Version:
01/02/1999
File size:
95.6 KB
File name:
ti018cen.pdf
-
-
-
Operating Instruction (BA)
Operating Instructions CPA 530
Immersion Assembly for pH/Redox Measurement
EN 01/11/1999Language:
English
Version:
01/11/1999
File size:
164.2 KB
File name:
ba018cen.pdf
-
-
-
Special Documentation (SD)
SD DipFit W CPA530
Important information on dimensions
EN 14/09/2024Language:
English
Version:
14/09/2024
File size:
355.4 KB
File name:
SD03320CEN_0124-00.pdf
-
Search spare parts by number in drawing
60 spare parts & accessories
60 spare parts & accessories
60 spare parts & accessories
-
o-ring-set medium side EPDM
-
Sealing
Drawing numberOrder code130,140,1550044657 -
-
O-ring-set medium side Viton for CPA510
-
Sealing
Drawing numberOrder code130,140,1550044658 -
-
o-ring ID17.17 W1.78 Vit.
-
Sealing
Drawing numberOrder code12050009964 -
-
o-ring ID17.17 W1.78
-
Sealing
Drawing numberOrder code12050010365 -
-
o-ring ID59.7 W5.3 EPDM
-
Sealing
Drawing numberOrder code23050012186 -
-
notched pin 3x8
-
Assembly/armature accessory
Drawing numberOrder code1050034737 -
-
supporting rin
-
Assembly/armature accessory
Drawing numberOrder code2050041208 -
-
stud
-
Assembly/armature accessory
Drawing numberOrder code3050041210 -
-
Electrode holder CPA510/530
-
Connection (process)
Drawing numberOrder code4050056187 -
-
cover
-
Assembly/armature housing
Drawing numberOrder code5050041256 -
-
sleeve
-
Assembly/armature housing
Drawing numberOrder code6050053069 -
-
Lower part DIPSYS holder
-
Adapter housing/cable entry
Drawing numberOrder code7051502169 -
-
supporting socket
-
Adapter housing/cable entry
Drawing numberOrder code8050045878 -
-
thrust ring
-
Adapter housing/cable entry
Drawing numberOrder code9050044516 -
-
screw cap 27x1.5
-
Adapter housing/cable entry
Drawing numberOrder code10050045879 -
-
cable screwing PG16 reduced
-
Adapter housing/cable entry
Drawing numberOrder code16050015203 -
-
cutting ring
-
Adapter housing/cable entry
Drawing numberOrder code11050044527 -
-
flange bushing
-
Assembly/armature housing
Drawing numberOrder code17050045895 -
-
flange D63 NW50
-
Connection (process)
Drawing numberOrder code18050012207 -
-
adapter ring
-
Adapter housing/cable entry
Drawing numberOrder code19050043906 -
-
tube 14x2
-
Hose/hose accessories
Drawing numberOrder code20050012391 -
-
protection cap
-
Assembly/armature accessory
Drawing numberOrder code21050059498 -
-
screw cap D 63
-
Fixing
Drawing numberOrder code22050008948 -
-
threaded part D 63
-
Assembly/armature housing
Drawing numberOrder code24050010744 -
-
pipe
-
Pipes
Drawing numberOrder code25050043907 -
-
flange bushing
-
Assembly/armature housing
Drawing numberOrder code26050012209 -
-
fastening flange
-
Connection (process)
Drawing numberOrder code27050009339 -
-
threaded part
-
Fixing
Drawing numberOrder code28050045880 -
-
fastening flange
-
Connection (process)
Drawing numberOrder code29050009337 -
-
star knob
-
Connection (process)
Drawing numberOrder code30050009424 -
-
flat gasket ring 104x82x3
-
Sealing
Drawing numberOrder code31050008958 -
-
holding ring
-
Fixing
Drawing numberOrder code32050054034 -
-
binder
-
Assembly/armature accessory
Drawing numberOrder code33050054031 -
-
threaded pin M6x12 1.4401 DIN 417
-
Fixing
Drawing numberOrder code34050042931 -
