Level measurement

Continuous level measurement and point level detection in liquids and bulk solids

Constant product quality, plant safety and economic efficiency - these are important aspects for any level measuring point.
Levels in liquids, pastes, bulk solids or liquefied gases are often measured in tanks, silos or movable containers. For continuous, interface and density measurement as well as for point level detection a broad range of measuring principles is available. Endress+Hauser supports you from planning through commissioning and also maintenance of your measuring point.

Benefits

For every measuring task the right solution
As world market leader in level measurement, Endress+Hauser guarantees asset protection
Worldwide support and service
Know-how for the entire life cycle of your product

Level measurement

Our product finder helps you to search for suitable measuring devices, software or system components via product characteristics. Applicator leads you through an individual product selection via application parameters.

Frequently asked questions

Why is my radar level gauge jumping high?

When radar or guided microwave transmitters unexpectedly jump up the scale it can be due to a number of reasons;
Increased noise at the antenna due...

Show more

When radar or guided microwave transmitters unexpectedly jump up the scale it can be due to a number of reasons;
Increased noise at the antenna due to build-up or condensation
Reduction in target echo strength due to foam formation or turbulence
Incorrect parameter setting or lack of mapping to the empty vessel during commissioning
The Micropilot free-space radar and Levelflex guided microwave transmitters from Endress+Hauser feature Multi-Echo tracking to help ensure reliable operation.

Show less
Are microwave level transmitters affected foam?

When dealing with foaming media the general principle is the lower the transmission frequency of the microwave device, the better the penetration...

Show more

When dealing with foaming media the general principle is the lower the transmission frequency of the microwave device, the better the penetration of foam.
The Levelflex guided microwave transmitter from Endress+Hauser operates at 1GHz and is capable of reliably following liquid level below foam, but it is not well suited to vessels with agitation.
The Micropilot free-space radar transmitter from Endress+Hauser is available in three different frequencies.
Find out more here

Show less
How can I measure the interface between oil and water?

It is possible to measure the interface between two liquid media if there is a big enough difference in density (with a float displacer),...

Show more

It is possible to measure the interface between two liquid media if there is a big enough difference in density (with a float displacer), conductivity (with a capacitance probe) or dielectric (with a guided microwave transmitter).
The Endress+Hauser Levelflex FMP55 combines guided microwave and capacitance technologies to improve detection of the interface layer even with an emulsion present.
For further information, get in touch.

Show less

Radar level measurement

Radar level measurement offers reliable non-contact, maintenance-free measurement in liquids and bulk solids. Micropilot sensor is a safe solution even under extreme process conditions.
Vibronic point level detection

Vibronic point level detection offers safe overfill prevention in liquids and bulk solids. Liquiphant and Soliphant switches are the safe solution even under extreme process conditions.
Guided radar level measurement

Guided radar level measurement offers reliable measurement in liquids and bulk solids. Levelflex sensor is a safe solution even under extreme process conditions.
Ultrasonic level measurement

Non-contact ultrasonic level measurement works in liquids and bulk solids. Prosonic level sensors are a proved as well as cost-effective solution for level measurement.
Capacitance level measurement

Capacitance continuous level measurement and point level detection works in liquids and bulk solids. Liquicap, Liquipoint, Solicap and Minicap sensors are simple and cost-effective probes.
Hydrostatic level measurement

Hydrostatic level measurement with pressure transmitters for liquid applications. Deltapilot or Waterpilot devices with Contite measuring cell are unaffected by possible foam formation.
Conductive level measurement

Conductive switches offering simple and safe point level detection in conductive liquids. Liquipoint suites for a wide range of applications.
Float switch level measurement

Float switch level measurement is a simple and cost-effective solution for point level detection in liquids. Liquifloat works as pump protector or level alarm in open basins.
Radiometric level measurement

Radiometric level measurement offers non-contact continuous measurement and point level detection in liquids or solids. Radiometric sensors are a safe solution even under extreme process conditions.
Paddle switch level measurement

Paddle switch level measurement for point level detection in bulk solids. Soliswitch is extremely robust and cost-effective.
Servo level measurement

Servo level measurement provides continuous level measurement in liquids. The tank gauging instrument Proservo is used for custody transfer and inventory control applications.
Electromechanical level measurement

Continuous electromechanical level measurement in bulk solids with Silopilot devices.
Microwave barrier
level measurement

Microwave barriers are suitable for point level detection in bulk solids. Non-contact Soliwave sensors are nearly unaffected by process conditions.

Choosing your next level measurement solution?

Choosing your next level measurement solution?

Finding the ideal solution is easy with the wide range of measuring technologies available from Endress+Hauser.
How the wireless level sensor optimises your logistics

How the wireless level sensor optimises your logistics

All the advantages of digital radar sensors for your mobile and stationary level measurement.
The new Micropilot 80 GHz radar range

The new Micropilot 80 GHz radar range

All the benefits of the new generation of 80 GHz radar sensors for your level measurement.
For solid applications: New generation 80 GHz radar sensors

For solid applications: New generation 80 GHz radar sensors

All of the benefits of the new generation of 80 GHz radar sensors for level measurement in the primaries and metals and mining sectors.
For demanding applications: 80 GHz radar Micropilot

For demanding applications: 80 GHz radar Micropilot

All the benefits of the new generation of 80 GHz radar sensors for level measurements in the chemical and oil and gas industry.
For hygienic applications: Micropilot 80 GHz radar

For hygienic applications: Micropilot 80 GHz radar

All of the benefits of the new generation of 80 GHz radar sensor for hygienic level measurements in the life sciences, food and beverage industries.
Particularly small, exceptionally powerful: the Compact Line

Particularly small, exceptionally powerful: the Compact Line

All the advantages of the Compact Line for hygienic applications in the Food & Beverage and Life Sciences industries.
